BMS 60V 40A 16S

60V 40A BMS for 60V lithium battery packs

BMS card for lithium batteries.

This module allows you to control and equalize the various series of cells.

TECHNICAL DATA:

-Working voltage 67.2V
-Number of cells 16S
-Working temperature -20°C- 45°C
- Charge current 5A MAX
-Rated inrush current 40A
-Protections: Overload, underload and short circuit

MEASUREMENTS: 12.5 x 6.5 x 1 cm

WARNINGS : The conditions of installation and use of this product must be respected otherwise there is a risk of damage to the BMS and battery pack. • Respect the operating parameters such as operating temperature, maximum currents and voltages in order not to risk damaging the BMS and the battery pack. • Use measures and safeguards to prevent damage from electrostatic discharge during testing, installation and whenever handling the BMS. • Use chargers suitable for the type of battery pack in which the BMS is installed. The use of inappropriate chargers can cause damage to the battery pack and the BMS, as well as explosions and fires with damage to things and people. • It is not possible to use several BMS in series or in parallel. You risk damage and explosion of the battery pack and BMS. • Use this BMS only with battery packs constructed with high quality cells. • Uninstall the BMS immediately and contact the supplier in case of malfunction or abnormal behavior during its use. • This BMS must be installed by qualified personnel familiar with all instructions and precautions for use.
