SW900 Display WITH USB LCD Multifunction 24V / 36V / 48V

SW900 Display WITH USB Multifunction LCD

- This display DOES NOT INTERFACE with KT controllers and components.

Technical specification:
Material: LCD, plastic
Voltage level: 24V, 36V, 48V
Package Includes: 1 x SW900 USB LCD Display

Display setting function:
Long press the instrument up and down buttons to access the instrument settings.
P01: backlight brightness, level 1 is the darkest, level 3 is the brightest.
P02: Mileage Unit, 0: KM; 1 MILE.
P03: Voltage level: 24V, 36V, 48V.
P04: Sleep time: 0, no sleep; other numbers are the suspension time, range: 1-60; unit minutes.
P05: Assist gear 1-9
P06: Wheel diameter: unit, inch; accuracy: 0.1.
P07: Number of speed magnets: range: 1-100.
P08: Speed ??limit: 0-100% speed percentage range, 100 means 100% speed.
P09: starting from zero, starting setting different from zero, 0: starting from zero; 1: non-zero start.
P10: Driving mode setting 0: Power assisted driving (throttle is invalid).
1: electric drive (turning the handle to drive, the power gear is invalid at this time).
2: Power-assisted drive and electric drive coexist simultaneously.
P11: Assist sensitivity setting range: 1-24.
P12: Assisted start intensity setting range: 0-5.
P13: Setting the type of servo magnet There are three types of magnets 5, 8 and 12, of which 5 and 8 are single Hall servo sensors.
Setting 12 is used for the Assist Hall dual pedaling sensors.
